This page is to provide the option of purchasing either the BoosterPack button throttle OR the flick throttle. (FYI the 3D printable models for these assemblies are available on Thingiverse here and here)
Button Throttle includes the printed case (Black PLA), a Momentary Push Button Switch (Normally Open), a 10k resistor, and the nut & bolt to clamp it on. Fits .875″(22mm) diameter handlebars.
Flick throttle includes the three printed case parts (Black PLA), a torsion spring, and the nut & bolt to clamp it on. Fits .875″(22mm) diameter handlebars.
Parts Required to finish either throttle that are NOT included:
- Electrical wires not included. I recommend a 5′ long 22AWG cable, 2-wires for the button throttle, 3 wires for the flick throttle.
- Both will require a modified Servo Tester, as seen here.
- Wiring the servo tester is different for each throttle. For the button throttle, see image immediately below, and STEP 10 of the instructables for more details.
- For wiring the flick throttle see images and video demo below.
Relevant Video Support/Demonstations:
